Free linear tobogan
Materials and technology: The 900 mm slide channel is built with LRTM technology and high-quality materials that require minimal maintenance.
Gelcoat finish: The internal and external surfaces are treated with gelcoat to enhance durability, resistance to weather, wear, and UV rays, while also ensuring a pleasant aesthetic appearance and optimal sliding performance.
Assembly: The elements are assembled with AISI 304 stainless steel bolts, ensuring stability and safety.
Support structure: The structure consists of galvanized steel columns and anchoring arms, fixed to reinforced concrete foundation blocks.
Includes a climbing tower made of metal carpentry.
Download the catalog sheet PDF
TECHNICAL DATA
Slide for swimming pools and water parks.
| Cod. | Starting hight (m) | waterslide length (m) | Catch unit length (m) | Slope | Connection (mm) | Flow ride (mc/h) |
|---|---|---|---|---|---|---|
| 021024 | 2.70 | 13.80 | 5.50 | 16% | Ø140 | 90 |
Request technical sheet and/or more information
