Drain nozzle for overflow channel with plate
Drain nozzle for installation inside the channel for swimming pools with prefabricated structure/reinforced concrete with PVC membrane or with waterproofing system with ceramic/mosaic covering. Complete with cover small plate.
It is made of PVC with high resistance to pressure and wear, complete with PVC counter flange, A2stainless steel screws.
PVC flange external diameter 140 mm.
Download the catalog sheet PDF
TECHNICAL DATA
Drain nozzle for installation inside the channel for swimming pools. Complete with cover small plate.
| Cod. | Diameter (mm) | Connection (inch) | Flow ride (mc/h) |
|---|---|---|---|
| 021017 | Ø 140 | 3" | 8 |
Product compliant with the standards UNI EN 13451-1:2016 | UNI EN 13451-3:2016 | UNI 16713-2:2016
Request technical sheet and/or more information
